1000 kg Automatic Sliding Operator

The 1000 kg Automatic Sliding Operator is a product designed for extra-large, specialized, or high-security doors; manufactured by the Chinese company OWNIC, it is capable of handling doors constructed from ultra-thick materials and featuring complex structures.

Technical Data:

Product Features

1. Ultra-Heavy-Duty Load Capacity

The 1000 kg Automatic Sliding Door Operator supports a maximum single-leaf door weight of 1000 kg. It is ideally suited for ultra-thick steel doors, shielded doors, and large-scale industrial doors, ensuring long-term load-bearing stability without deformation or performance degradation.

2. Industrial-Grade Drive System

To ensure stable operation, the product is equipped with a high-power industrial motor and a reinforced transmission structure, delivering consistent power output and continuous, reliable performance.

3. High-Precision, Smooth Operation

Heavy-duty doors are often prone to vibration and excessive noise during operation; however, this sliding door operator employs a "soft start" and "soft stop" control mechanism. Even when driving multi-ton door bodies, it maintains smooth opening and closing, effectively minimizing vibration and mechanical shock.

4. Intelligent Control and Expandability

The 1000 kg sliding door operator supports PLC control systems and can be seamlessly integrated with access control systems, interlock controls, and remote management platforms. Recognizing the complexity inherent in industrial projects—where centralized management may be challenging to implement—key parameters such as operating speed, delay duration, and opening width are fully adjustable to meet specific operational requirements.

What are the typical application scenarios for a 1000 kg Automatic Sliding Door Operator?

The application of the 1000 kg Automatic Sliding Door Operator extends far beyond standard commercial buildings. As a specialized manufacturer, we do not recommend over-specifying equipment for your project; however, during the solution design phase, if your project resembles any of the common examples listed below, we may recommend this ultra-heavy-duty sliding door operator.

1. Medical and Scientific Research Sectors: Areas such as linear accelerator rooms in oncology hospitals, Gamma Knife treatment rooms, or industrial non-destructive testing chambers require door systems of the ultra-heavy-duty class.

Why is the 1000 kg class mandatory? To completely block high-energy radiation, the interior of the door leaf must be filled with extremely thick lead plates or high-density concrete. The weight of such door leaves typically ranges from 800 kg to 1500 kg.

Core Requirements: The opening and closing of the door must be exceptionally smooth, and—upon closing—it must achieve a perfect seal to prevent any radiation leakage.

2. Aerospace and Heavy Industry: Door systems in areas such as aircraft maintenance hangars, shipyard paint booths, or large-scale assembly workshops require the use of this product.

Why is the 1000 kg class mandatory? The door openings in these large hangars and workshops feature massive spans; the door leaves themselves are constructed from heavy-gauge steel channel frames and double-sided color-coated steel panels, resulting in a substantial inherent weight.

Environmental Challenges: In addition to the weight of the door leaves and the wide spans of the openings, door systems installed in these areas must also withstand immense outdoor wind pressure. The powerful industrial motor within the 1000 kg sliding door operator is capable of overcoming wind resistance, ensuring that the massive door can still be securely closed—even under adverse weather conditions.

3. National Security and Financial Centers: Commonly utilized for bank vaults, government classified archives, air-raid shelter exits, or high-end private safe rooms.

Why is the 1000 kg class mandatory? The door leaves are constructed from multiple layers of cut-resistant steel plates, ceramic composites, and drill-resistant alloys; this armored design results in an extremely heavy door structure.

Core Advantages: When paired with a high-strength electromagnetic locking system, this ultra-heavy-duty sliding door operator provides a level of physical resistance against forced entry and vandalism that far exceeds that of standard doors.

4. Architectural Artistry: Oversized stone slabs or specialized glass doors—often weighing in the 1000kg range—utilized in select modern art museums, global flagship stores of luxury brands, or the grand lobbies of landmark buildings.

Why the 1000kg Class is Essential: When used as movable door panels, monolithic natural marble slabs or extra-large laminated tempered glass panels (exceeding 25mm in thickness) offer exceptional aesthetic appeal and distinct character, but they are extremely heavy.

Core Advantage: These massive door panels possess immense inertia. Only a 1000kg-class sliding door operator—equipped with advanced variable-frequency braking technology—can ensure that these expensive architectural materials do not suffer structural vibration or damage caused by abrupt stops during movement.

5. Laboratories & Chemical Facilities: Specialized airtight or explosion-proof isolation doors used in projects such as pharmaceutical sterilization chambers and storage facilities for flammable or explosive chemicals.

Why the 1000kg Class is Essential: The door body is not only heavy, but upon closing, it also requires a mechanical mechanism to exert immense compressive force against the sealing strips.

This process demands the powerful terminal torque provided by a high-capacity sliding door operator to achieve a completely airtight seal or effective explosion-proof isolation.
