Automatic Swing Glass Door

If you are looking for a reliable manufacturer of automatic swing glass doors, please contact OWNIC. Based in China with over 40 years of experience, we are a leading enterprise in the industry. This product is part of our commercial door series and facilitates barrier-free access.

Application:

hotels, banks, office building, stores, etc.

PRODUCT FEATURES

1.Adopting microcomputer chip, intelligent control of door operation.

2.Equipped with high efficiency brushless DC motor, long life, low noise and high power.Sensitive opening and closing, safe and reliable.

3.Various access modes are available, such as infrared sensor, microwave sensors, and key card readers.

4.Apply to ordiary 90 degree open and close door body and framed, frameless glass door or other solid door.Suitable for all kind of small area occasions, such as banks, office buildings and other lobby or corridors of the narrow entrances and exits, reflecting the humanized service.

Technical Data:

Operating Principle

While retaining the classic layout of traditional swing doors, the Automatic Swing Glass Door enables contactless, effortless, and secure intelligent passage; it represents a high-end automatic door product that has undergone significant design and technological upgrades by OWNIC.

This door is compatible with a variety of activation methods—including infrared sensors, wall-mounted buttons, access control card readers, and remote controls. Upon detecting an opening command, the motor drives the door leaf to pivot around its hinges through an arc of 90° to 110°, thereby facilitating passage. After a preset delay, the door closes slowly; equipped with obstruction-reversal and anti-pinch safety features, it ensures a safer passage experience.

In the event of a power failure, the door remains compliant with fire evacuation regulations and can be manually pushed or pulled open.

How does an Automatic Swing Glass Door ensure safety?

Safety is a critical challenge in the design of swing doors. As a specialized manufacturer, OWNIC addresses this issue through a three-tiered protection system.

During the opening or closing cycle, should the door leaf encounter an obstruction, the motor will immediately detect the resulting current anomaly and either halt its movement or reverse direction.

The second layer of protection involves optional side-mounted safety sensors. We recommend installing laser or infrared sensors along the edges of the door leaf to continuously monitor its opening path; if a person is detected lingering in the vicinity, the door will remain closed or cease its swinging motion.

Finally, we recommend utilizing the control unit to adjust the initial opening speed and the door's hold-open duration. These parameters can be fine-tuned based on the pedestrian traffic volume at your specific project site, thereby providing ample reaction time for passersby.

FAQ

Q: What is the service life of the Automatic Swing Glass Door?

A: Under conditions of normal use and regular maintenance, the expected service life of the automatic swing door can reach 10 to 15 years. The specific lifespan depends on usage frequency and environmental conditions.

Q: Is this product suitable for accessible design?

A: The automatic swing door is particularly well-suited for accessible design; its opening force can be adjusted to ≤50N, and it can be equipped with ultra-quiet door closers, making it ideal for settings such as hospital wards, nursing homes, and similar facilities.

Q: Does the automatic swing door offer fire-resistant capabilities?

A: The automatic swing doors provided by OWNIC can be specified with various fire-resistance ratings according to client requirements. They are equipped with corresponding fire-resistant core materials and hardware to ensure effective containment of fire spread in the event of a fire.
